○ Good flexibility ensure moving freely in the storage yard
○ Wide working scope and upper carriage could swing in 360 o which realized picking heavy scrap in the storage heap extensively
○ Wide shear angle and the shears could working in pitching and swinging in 360 o
○ Hydraulic drive, protecting environment and safe, which realized to cut iron scrap with non-oxygen
○ Reduce the dimension requirement of iron scrap
○ Materials could separating
○ The blade of shears could change easily

No.

Item

Unit

Date

1

Machine weight

t

39

2

Diesel engine

Model

Cummins water-cooled

Power

kW/rpm

194

Speed

2000

3

Hydraulic system

Type

Variable system by negative flow control and with two pumps&loops

Pressure of main oil circuit

MPa

2×264

Flow of main oil circuit

L/min

29.4

4

Performance

parameter

Swing speed

r/min

0-9.25

Travel speed

km/h

3.0/5.0

Max. pulling force

kN

307.8

Ground pressure

MPa

0.086

5

Working date

Boom length

mm

6200

Stick length

mm

3000

Max. cutting height

mm

8684

Max. cutting radius

mm

11487

Max. cutting depth

mm

7665

6

The model of shears be matched

RS800HRV

No.

Component

Manufacturer

1

Diesel engine

Cummins/America

2

Main pump

Kawasaki/Japan

3

Main valve

Kawasaki/Japan

4

Swing motor

Kawasaki/Japan

5

Travel motor

Kawasaki/Japan

6

Pilot valve

Kawasaki/Japan

7

Hydraulic hose+ System seal

Parker/America

8

Cylinder seal

Trelleborg/America

9

Air-condition system

Wuhan Jindong/China

10

Shears

DEMO/Korea
